Creating QML Controls From Scratch: Spinner

By Chris Cortopassi

Spinner

Continuing our QML Controls from Scratch series, this time we will implement a Spinner, also known as a busy indicator. Spinner indicates the progress of a long-running operation when the progress percentage is unknown. (For known percentages, we'd use a ProgressBar.) Spinner uses a Timer to animate rotation. Normally, a designer would provide us with a .png asset to rotate an Image, but for this example we rotate an array of circles, implemented with Rectangle. Spinner has no public properties.

Spinner.qml

import QtQuick 2.0

Item {
    id: root

// public

// private
    width: 500;  height: 100 // default size

    Item { // square
        id: square

        anchors.centerIn: parent
        property double minimum: Math.min(root.width, root.height)
        width: minimum;  height: minimum

        Repeater {
            id: repeater

            model: 8

            delegate: Rectangle{
                color: 'black'

                property double b: 0.1
                property double a: 0.25

                width: ((b - a) / repeater.count * index + a) * square.height;  height: width
                radius: 0.5 * height

                x: 0.5 * square.width  + 0.5 * (square.width  - width )  * Math.cos(2 * Math.PI / repeater.count * index) - 0.5 * width
                y: 0.5 * square.height - 0.5 * (square.height - height)  * Math.sin(2 * Math.PI / repeater.count * index) - 0.5 * height
            }
        }
    }

    Timer {
        interval: 10
        running: true
        repeat:  true

        onTriggered: square.rotation += 2 // degrees
    }
}



Test.qml

import QtQuick 2.0

Spinner{}



Summary

In this post, we created a Spinner. Use it to show progress of a long-running operation in cases where you don't know the  progress percentage. In the next blog, we'll create a Dialog. The source code can be downloaded here.
